GSM/GPS Communication module

PATRIOT EU is a GPS-GSM module utilizing the newest tracking technology. This security system was designed with the mobile and PC application in mind, allowing for two-way communication between you and the unit. You can localize your vehicle on the command and conversely, PATRIOT EU will automatically inform you about the state of your vehicle via push notifications. Additionally, the monitoring abilities can be enhanced through the speed limit, zone-crossing, and ignition-start notifications. Thanks to the integrated 3D sensor, the unit detects unauthorized movements, tilting, and accidents. By connecting the unit to the alarm system, you will be notified about the intrusion. The optional output installation allows you to control various car features via the app as well. The installation is quick and easy thanks to its small dimensions (68 x 70 x 23 mm) and integrated GPS and GSM antennas. The integrated back-up battery guarantees the unit stays functional even after the main power supply is disconnected.

The PATRIOT EU unit is equipped with a data SIM card which includes a Europewide data tariff.  The first year is free of charge.


Download the application

Choose the operating system of your mobile phone

Functions


MOBILE APPLICATION
The communication between you and your vehicle is realized via the mobile application. You can localize the vehicle, control the output, and receive alarms.


TILT DETECTION
The unit detects the tilting of the vehicle. This way the system will inform you about the wheel theft.


ALERT FROM CAR ALARM
By connecting the module to the OEM car alarm, the information about the intrusion will be transmitted through the mobile application.


CAR EMERGENCY
In the case of an accident, the module will transfer an alarm message including the position of the event.


UNAUTHORIZED MOVEMENT DETECTION
The module triggers an alarm in the case of vehicle movement with the ignition turned off. For instance, when the car is being towed away.


CAR BATTERY VOLTAGE DROP OR DISCONNECTION
The unit sends an alarm if there is a drop in voltage or the vehicle battery gets disconnected.


VEHICLE LOCALIZATION
PATRIOT EU enables you to localize your vehicle on the command.


OUTPUT CONTROL
Please, discuss the possibility of this installation with the car service.


ZONE
The zone allows you to define an area on the map which prompts the unit to send the alert when the zone borders are crossed.


SPEED LIMIT
If the defined speed limit is exceeded, you will be notified by the alert.


VEHICLE INSPECTION
Patriot EU notifies you of the upcoming vehicle inspection.


VIRTUAL GARAGE
Virtual garage warns you when the ignition turns on during the specified interval when the vehicle is supposed to be inactive.


Hardware

The PATRIOT EU communication module is based on cutting-edge technology. It is designed to protect the vehicle and transmit the information via the mobile application as well as SMS (only for the Czech telephone numbers beginning with +420). It can be installed either as a standalone device, or it can be connected to the car alarm. The module is equipped with a 3D acceleration sensor which not only detects unauthorized movements and tilting but accidents as well. Thanks to its small dimensions and integrated GPS and GSM antennas, the installation is quick and easy. The backup battery guarantees the unit to remain functional even after disconnecting the main power supply. The user interface features vehicle localization, remote output control, speed limit, startup, and zone alerts.

  • Small dimensions (68 x 70 x 23 mm)
  • Low consumption
  • High-precision GPS
  • Remote firmware updates
  • Integrated GPS/GSM antennas
  • 3D acceleration sensor
  • Backup battery
  • Integrated OEM car alarm detection

Technical specification



GSM Modul SARA-G3 Quadband 850 / 900 / 1800 / 1900 MHz
Communication Push notifications, SMS (+420 tel. numbers only)
GPS 72-channel receiver, GPS/QZSS L1 GLONASS L10F, BeiDou B1l, Galileo E1B/C, SBAS: WAAS, EGNOS, MSA, GAGAN sensitivity up to -167 dBm
3G acceleration sensor 3-axis gravity sensor
Output 1 output open collector (500mA)
Power supply 12 - 24 DC
Consumption Sleep mode < 4mA; Max. 500mA
Time synchronization Date and time are synchronized with GPS
Dimensions 68 x 70 x 23 mm
Weight 110 g
Operating temperature -20°C to +60°C
